Humidity Sensor
The Urban.io Humidity Sensor allows you to accurately monitor the relative humidity of the air within a room or enclosure. This sensor measures the relative moisture of the air around the device.
This product is designed for usage with an Urban.io IoT Gateway. In ideal conditions with correct orientation of sensors and gateway antennas the following ranges can be achieved.
- Up to 5km line-of-sight where there are no obstructions between the gateway and the sensor and they are placed on the same horizontal plane.
- 500m non-line-of-sight in an enclosed space where there are one or more obstructions (objects, walls, buildings) between the gateway and the sensor and it is placed on the same horizontal plane.
This product is designed for application in normal indoor and certain outdoor environments. The gateway housing is IP65 rated and as such is designed to be water and dust resistant as well as generally resistant to direct sunlight. However the 240v Power Adapter is not rated for outdoor usage.
Urban.io proactively supports the interfacing of IoT sensor data with all industry leading Asset Management, Field Force and Work Management, Data Analytics and Machine Learning Platforms. We provide the following Public APIs as well as pre-built API Adapters for the following Enterprise IoT Systems :
- API publics : MQTT, Rest Web Services
- API adaptés : AWS IoT Core, IBM Watson IoT, Azure IoT Hub
Respond to emergencies
more quickly
Respond to emergencies more quickly
Cloud reporting platform
IoT API
Email/SMS alerts
Humidity Sensor features :
General Sensor Features
Gateway to sensor network range
500m indoor
5km outdoor
Operating Temperature
-40°C to 85°C
Power Supply
3.0 V CR2477 coin cell battery (replaceable)
Battery life
2 years under normal operation
Reading frequency
Sample at 10-minute intervals
Data transmission frequency
10 minute interval
Primary Sensing Element
Relative humidity sensor integrated
circuit
Secondary Sensing Elements
Fault detection
(loss of sensing element)
IoT network connectivity
(Signal to Noise levels “SNR”)
IoT device battery Level
(% of remaining battery level)
Technical Specifications :
Maximum resolution over measured electrical range | Measurement range | Calibration / Drift | Accuracy | Accuracy — outside core | Temperature range (limited by battery) | Enclosure rating |
4,095 calculated RH% [0% to 100%] | 0% to 100% RH | No | ±3% RH [between 20% to 80%] | ±5% RH [outside 20% to 80%]-20°C to +85°C | -20°C to 85°C | IP67 |
Power specifications :
Supply Voltage | Current consumption — sleep mode | Current consumption — sensor active sampling mode | Current consumption — radio RX mode | Current consumption — radio TX mode (max) |
2,0 - 3,4 VDC | 6 uA | 150 uA when active | 25 mA for 0,5 seconds | 100 mA for 0,5 seconds |
915-925 MHz
Suitable for South East Asia, Australia, North/South America.
863-870 MHz
Suitable for Africa, Middle East, Europe.
779-787 MHz
Suitable for China.
Mounting and dimensions :
Length : 73 mm (with antenna)
Height : 29 mm
Width : 44 mm
Weight : 85 g
Example Applications
Greenhouse humidity
monitoring
Agriculture environment
monitoring
HVAC dehumidification
monitoring
(mould detection)
