FasTest NuJaws JNL series connector, lever handle actuated.
Custom "stepped" design to grip the 22.5mm ID, extending into the 16mm ID to seal.
Aluminum & stainless steel with Delrin handlematerial. Neoprene main seal.
1/8" BSPP media inlet port.
Rated for use at 1.5 bar test pressure.

Fastest JNL Série
Connexion par levier manuel
pour tube droit diamètre intérieur 1.625 inch (41.3) +0.10 in/-0.010 in (+/-0.25mm)
Connectique arrière : Femelle 1/8 NPT
Pression de travail jusqu'à 1000 psi (68.9 bar)

Fastest JNL2M Série
Connexion par levier manuel
pour tube droit diamètre intérieur 41,7mm +/-0.2mm avec 25 mm de porté
Connectique arrière : Femelle 1/8 BSPP
Pression de travail maximum 52 bar
Construction en Inox, Aluminium Anodisé, Acétal avec joint néoprène

JXL0 EXTERNAL BASE CONNECTOR

JXL0 EXT 250 LEVER

JXL0 EXT 312 LEVER

JXL0 EXT 375 LEVER

JXL0 EXT 500 LEVER

JXL0M EXT 375 LEVER 1/8 BSPP TERM

JXL0M EXT 500 LEVER 1/8 BSPP TERM

Fastest MET Serie
Manual twist sealing connection to male 1/2 BSPP (G) thread.
Termination : Female 1/8 NPT
Pressure Rating: up to 4000 psi (275,6 bar)
Stainless Steel construction with Buna-N seal.
Main seal : Urethan

JXL1 EXT 625 LEVER

JXL1 EXT 750 LEVER

Fastest JNL Serie
Manual lever actuated internal grip
for Imperial External tubes 0.875 +/- .010
Termination : Female 1/4 NPT
Pressure Rating: 10 mtorr to 1000 psi (68.9 bar)
Materials of Construction : Anodized Aluminium, Stainless Steel and Acetal (POM)

JXL1M EXT 750 LEVER 1/4 BSPP TERM

Fastest JNL Serie
Manual lever actuated internal grip
for Imperial External tubes 0.875 +/- .010
Termination : Female 1/4 BSPP
Pressure Rating: 10 mtorr to 1000 psi (68.9 bar)
Materials of Construction : Anodized Aluminium, Stainless Steel and Acetal (POM)

250 RQD B SLEEVE

PISTON B

POPPET

250 POPPET BACK
